Description
Features
- Multistage centrifugal pump for very high head
- Several impellers in series inside one casing
- Stage count built to the head your duty needs
- Pressure builds gradually across stages for smooth running
- Reliable operation under sustained high pressure
- Compact for the pressure it delivers
- Suited to continuous boiler-feed and booster duty
- Head up to 280 m, the highest in the range
- Pressure up to 28 kg/cm²
- SS, cast iron, cast bronze, and cast steel construction
Materials
- SS-304 / 304L, SS-316 / 316L
- Cast Iron
- Cast Bronze
- Cast Steel
Operating Range
- Capacity: Up to 75 m³/hr
- Head: Up to 280 m
- Discharge size: 25 to 65 mm
- Temperature: Up to 130°C
- Speed: Up to 3500 rpm
- Pressure: Up to 28 kg/cm²
Applications
- Boiler feed water and condensate extraction
- Water supply to high-rise buildings and hilly areas
- Reverse osmosis and booster plants
- Fire-fighting systems and sprinkler irrigation
- Mine dewatering and filter-press washing
- High-pressure duty in pulp and paper mills
