Description
Features
- Submersible design, pump and motor run fully submerged
- No priming and no separate pump room needed
- Non-clog handling of sewage, effluent, and muddy water
- Bi-directional twin mechanical seal keeps the motor sealed
- Surrounding liquid cools the motor for continuous duty
- Runs automatically on a level switch
- Dry-type squirrel-cage induction motor (2/4/6 pole)
- DOL, Star-Delta, or ATS connection
- Wear-resistant impeller, casing, and wear-plate options
- Single- and three-phase options up to 50 HP
Materials
- Cast Iron, Cast Steel (body)
- Optional wear parts:
- Bronze
- CF8 (SS-304), CF8M (SS-316)
- CD4MCU
Operating Range
- Capacity: Up to 500 m³/hr
- Head: Up to 45 m
- Delivery size: 32 to 200 mm
- Temperature: Up to 45°C
- Speed: Up to 1500 rpm
- HP: 0.75 to 50
Applications
- Muddy water transfer and dewatering of ponds
- Basements of large buildings and power plants
- Effluent transfer, ETP, STP, and waste-water plants
- Beverages, food, sugar, and dairy
- Swimming pools
- Hotels, hospitals, railways, chemical, steel, and cement
