Description
Features
- Corrosion-resistant polypropylene (non-metallic) construction
- Handles aggressive acids, alkalis, and corrosive chemicals
- Self-venting type casing, suitable for continuous service
- Dynamically and hydraulically balanced impeller with aerodynamic vanes
- Pump casing provided with external metal ring for structural stability
- Designed for extremely corrosive duties in process and chemical industries
- Double ball bearing with oil lubrication
- Sealing by externally or internally mounted mechanical seal, or gland packing
Materials
- PP (Polypropylene)
- PPCP
- UHMWPE
- PVDF
- Shaft: SS / EN 9
Operating Range
- Capacity: Up to 50 m³/hr
- Head: Up to 45 m
- Discharge size: 25 to 50 mm
- Temperature: Up to 120°C
- Speed: Up to 3500 rpm
- Pressure: Up to 4.5 kg/cm²
Applications
- Water and effluent treatment plants
- Electroplating, pickling, and steel rolling mills
- Transfer of HCl, sulphuric acid, alkali, and caustic liquid
- Scrubbing of corrosive gases (NH₃, CO₂, SO₃, Cl₂)
- Textile, paper, sugar, and food chemical handling
- Pickling line and scrubber duty in steel plants
