Description
Features
- Progressive cavity (positive displacement) design
- Single helical rotor turning in a twin-helix stator
- Smooth, non-pulsing flow, gentle on the liquid
- Handles sludge, slurry, and solids-laden liquids
- Suits shear-sensitive and viscous products
- Constant flow regardless of pressure or viscosity
- High pressure capability, up to 25 kg/cm²
- Low-speed running for long service life
- Full material range from cast iron to Hastelloy B & C
- Suitable for direct or geared drive
Materials
- Cast Iron, Cast Steel
- SS-304 / 304L, SS-316 / 316L
- Bronze, Alloy-20
- CD4MCU
- Hastelloy B & C
Operating Range
- Capacity: Up to 145 m³/hr
- Head: Up to 250 m
- Discharge size: 25 to 150 mm
- Temperature: Up to 120°C
- Speed: Up to 600 rpm
- Pressure: Up to 25 kg/cm²
Applications
- Sewage effluent and water treatment plants
- Sugar, starch, cement, pulp and paper
- Ceramics, chemicals, fertilizers, soap and detergents
- Paint, varnish, petrochemicals, vegetable oils
- Pharmaceuticals, breweries and distilleries
- Dairies, food and beverages, fruit processing
