  Hex Reducing Coupling 10000 psi

  TYA is the manufacturer of High Pressure Hex Reducing Couplings 10000 psi , 700 Bars. It has NPT Female Connection on both sides . Standard Material for Hex Reducing Couplings 10000 psi is SS 316 but is also available in Carbon Steel, Brass, Hastelloy , Inconel alloys , Monel alloys , Titanium , Super Duplex & Duplex . Common sizes are 1/4" NPT Female , 3/8" NPT Female , 1/2" NPT Female , 3/4" NPT Female , 1" NPT Female . High Pressure Fittings are used in almost all industrial applications where threaded connections are involved . It also used in Hydro testing setup .

  PART No.	P	PP	F	L
  	NPTF	NPTF	HEX
  FHPF/10K/HRC/4-2I	1/4"	1/8"	7/8"	0.95"
  FHPF/10K/HRC/6-2I	3/8"	1/8"	1-1/8"	0.95"
  FHPF/10K/HRC/6-4I	3/8"	1/4"	1-1/8"	1.13"
  FHPF/10K/HRC/8-2I	1/2"	1/8"	1-3/8"	1.19"
  FHPF/10K/HRC/8-4I	1/2"	1/4"	1-3/8"	1.37"
  FHPF/10K/HRC/8-6I	1/2"	3/8"	1-3/8"	1.37"
  FHPF/10K/HRC/12-4I	3/4"	1/4"	1-3/4"	1.40"
  FHPF/10K/HRC/12-6I	3/4"	3/8"	1-3/4"	1.40"
  FHPF/10K/HRC/12-8I	3/4"	1/2"	1-3/4"	1.53"
  FHPF/10K/HRC/16-4I	1"	1/4"	2-1/4"	1.63"
  FHPF/10K/HRC/16-6I	1"	3/8"	2-1/4"	1.63"
  FHPF/10K/HRC/16-8I	1"	1/2"	2-1/4"	1.76"
  FHPF/10K/HRC/16-12I	1"	3/4"	2-1/4"	1.76"

•

  Hex Adapter BSP M x F,10000 psi

  TYA is the manufacturer of High Pressure Hex Adapter BSP,10000 psi , 700 Bars. It has BSP Female Connection on one side and BSP Male Connection on the other side . Standard Material for Hex Adaptor ,10000 psi is SS 316 but is also available in Carbon Steel, Brass, Hastelloy , Inconel alloys , Monel alloys , Titanium , Super Duplex & Duplex . Common sizes are 1/4" BSP Female X 1/4" BSP Male, 3/8" BSP Female X 3/8" BSP Male , 1/2" BSP Female X 1/2" BSP Male, 3/4" BSP Female X 3/4" BSP Male, 1" BSP Female X 1" BSP Male. High Pressure Fittings are used in almost all industrial applications where threaded connections are involved . It also used in Hydro testing setup .

  PART No.	P	P1	0D	L	F
  	BSP F	BSP M	Inch	inch	HEX
  FHPF/10K/GA/2-2I	1/8	1/8	0.19	1.10	9/16
  FHPF/10K/GA/4-4I	1/4	1/4	0.28	1.40	3/4
  FHPF/10K/GA/6-6I	3/8	3/8	0.38	1.51	7/8
  FHPF/10K/GA/8-8I	1/2	1/2	0.47	1.94	1-1/16
  FHPF/10K/GA/12-12I	3/4	3/4	0.62	2.02	1-1/4
  FHPF/10K/GA/16-16I	1	1	0.88	2.28	1-5/8

•

  Hex Adapter Male x Female 10000 psi

  Hex Adapter NPTM X NPTF

  We make and stock Hex Adapter NPT Male X NPT Female in sizes 1/8 to 1 . Standards is NPT Threads .They are also available in BSP ,BSPT and Metric. Common sizes are 1/4″ NPTF  X 1/4″ NPTM, 3/8″ NPTF  X 3/8″ NPTM , 1/2″ NPTF  X 1/2″ NPTM, 3/4″ NPTF  X 3/4″ NPTM, 1″ NPTF  X 1″ NPTM

  PART No.	P	P1	0D	L	F
  	NPTF	NPTM	Inch	inch	HEX
  FHPF/10K/A/2-2I	1/8	1/8	0.19	1.10	9/16
  FHPF/10K/A/4-4I	1/4	1/4	0.28	1.40	3/4
  FHPF/10K/A/6-6I	3/8	3/8	0.38	1.51	7/8
  FHPF/10K/A/8-8I	1/2	1/2	0.47	1.94	1-1/16
  FHPF/10K/A/12-12I	3/4	3/4	0.62	2.02	1-1/4
  FHPF/10K/A/16-16I	1	1	0.88	2.28	1-5/8

  HEX REDUCING ADAPTOR NPT MALE x NPT FEMALE

  We make and stock Hex Reducimg Adapter NPT Male X NPT Female in sizes 1/8 to 1 . Standards is NPT Threads .They are also available in BSP ,BSPT and Metric.

  PART No.	P	P1	F	L
  	NPTF	NPTM	HEX
  FHPF/10K/RA/2-4I	1/8"	1/4"	3/4"	1.29"
  FHPF/10K/RA/2-6I	1/8"	3/8"	3/4"	1.29"
  FHPF/10K/RA/2-8I	1/8"	1/2"	7/8"	1.42"
  FHPF/10K/RA/4-2I	1/4"	1/8"	7/8"	1.33"
  FHPF/10K/RA/4-6I	1/4"	3/8"	7/8"	1.51"
  FHPF/10K/RA/4-8I	1/4"	1/2"	7/8"	1.70"
  FHPF/10K/RA/4-12I	1/4"	3/4"	1-1/8	1.70"
  FHPF/10K/RA/4-16I	1/4"	1"	1-3/8	1.89"
  FHPF/10K/RA/6-2I	3/8"	1/8"	1-1/8	1.39"
  FHPF/10K/RA/6-4I	3/8"	1/4"	1-1/8	1.57"
  FHPF/10K/RA/6-8I	3/8"	1/2"	1-1/8	1.76"
  FHPF/10K/RA/6-12I	3/8"	3/4"	1-1/8	1.76"
  FHPF/10K/RA/6-16I	3/8"	1"	1-3/8	1.95"
  FHPF/10K/RA/8-2I	1/2"	1/8"	1-3/8	1.70"
  FHPF/10K/RA/8-4I	1/2"	1/4"	1-3/8	1.88"
  FHPF/10K/RA/8-6I	1/2"	3/8"	1-3/8	1.88"
  FHPF/10K/RA/8-12I	1/2"	3/4"	1-3/8	2.07"
  FHPF/10K/RA/8-16I	1/2"	1"	1-3/8	2.26"
  FHPF/10K/RA/12-4I	3/4"	1/4"	1-3/4	2.06"
  FHPF/10K/RA/12-6I	3/4"	3/8"	1-3/4	2.06"
  FHPF/10K/RA/12-8I	3/4"	1/2"	1-3/4	2.25"
  FHPF/10K/RA/12-16I	3/4"	1"	1-3/4	2.44"
  FHPF/10K/RA/16-4I	1"	1/4"	2-1/4	2.31"
  FHPF/10K/RA/16-6I	1"	3/8"	2-1/4	2.31"
  FHPF/10K/RA/16-8I	1"	1/2"	2-1/4	2.50"
  FHPF/10K/RA/16-12I	1"	3/4"	2-1/4	2.50"

•

  Adapter BSP Swivel X BSP Male 60 deg cone,10000 psi

  TYA is the manufacturer of Adapter BSP Swivel X BSP Male 60 deg cone, 10000 psi as part of High Pressure Fittings and Valves 10000 psi, 700 Bars.
